Schneider Emergency stop rope pull switch XY2CH13250
Brand Name: Schneider
Model Number:XY2CE2A250/XY2CH13250/XY2CH13270H29
Protection Level: Standard
Send Inquiry
Product Details ofSchneider Emergency stop rope pull switch XY2CH13250
Schneider Latching Emergency Stop Rope Pull Switch
XY2C, 1NC+1NO, XY2CH13250
Product Description
>> What are the main features of Schneider Latching Emergency Stop Rope Pull Switch XY2CH13250?
|
Main
|
|
|
Range of product
|
Telemecanique Emergency stop rope pull switches XY2C
|
|
Product or component type
|
Latching emergency stop rope pull switch
|
|
Device short name
|
XY2CH
|
|
Housing colour
|
Red RAL 3000
|
|
Overvoltage category
|
Class I conforming to EN/IEC 61140 Class I conforming to NF C 20-030 |
|
Local signalling
|
Without pilot light
|
|
Number of cables
|
1
|
|
Trigger cable maximum length
|
30 m |
|
Body material
|
Zamak
|
|
Cover material
|
Stainless steel |
|
Reset
|
By booted push-button |
|
Contacts type and composition
|
1 NC + 1 NO |
|
Contact operation
|
Slow-break
|
|
Trigger cable anchor point
|
RH or LH side |
|
Connections - terminals
|
Screw clamp terminal, 1 x 0.5...2 x 1.5 mm²
|
|
Tightening torque |
0.8…1.2 N.m |
|
Cable entry number
|
3 tapped entry for Pg 13.5 cable gland |
|
Safety level |
Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1 Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1 Can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508 |
|
Safety reliability data
|
B10d = 4000000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear |
|
Marking
|
CE |
|
Mechanical durability
|
800000 cycles
|
|
Distance between cable support |
5 m
|
|
[Ie] rated operational current |
3 A at 240 V, AC-15, A300 conforming to EN/IEC 60947-5-1 appendix A 0.27 A at 250 V, DC-13, Q300 conforming to EN/IEC 60947-5-1 appendix A |
|
[Ithe] conventional enclosed thermal current |
10 A |
|
[Ui] rated insulation voltage
|
500 V (pollution degree 3) conforming to EN/IEC 60947-1 300 V conforming to UL 508 |
|
[Uimp] rated impulse withstand voltage |
6 kV conforming to EN/IEC 60947-1
|
|
Positive opening
|
With conforming to EN/IEC 60947-5-1 |
|
Maximum resistance across terminals |
25 MOhm conforming to EN/IEC 60255-7 category 3 25 MOhm conforming to NF C 93-050 method A |
|
Short-circuit protection
|
10 A cartridge fuse type gG conforming to EN/IEC 60269 |
|
Terminals description ISO n°1
|
(13-14)NO (21-22)NC |
|
Compatibility code
|
XY2CH |
>> What condition of the environment could Schneider Latching Emergency Stop Rope Pull Switch XY2CH13250 be used?
|
Environment
|
|
|
Standards
|
EN/IEC 60947-5-1 EN/IEC 60204-1 Machinery directive 2006/42/EC EN/IEC 60947-5-5 EN/ISO 13850 Work equipment directive 2009/104/EC |
|
Product certifications
|
UL category NISD emergency stop devices CCC |
|
Protective treatment
|
TC |
|
Ambient air temperature for storage |
-40…70 °C
|
|
Ambient air temperature for operation |
-25…70 °C |
|
IP degree of protection
|
IP65 conforming to IEC 60529 |
|
Vibration resistance
|
10 gn (f= 10…150 Hz) conforming to EN/IEC 60068-2-6 |
|
Shock resistance
|
50 gn 11 ms conforming to EN/IEC 60068-2-27 |
>> What is the dimension of Schneider Latching Emergency Stop Rope Pull Switch XY2CH13250?
|
Dimension
|
|
|
Width
|
80 mm
|
|
Height
|
92 mm
|
|
Length
|
196 mm
|
|
Net weight
|
0.865 kg
|
